Flange Ball Tow Bar
for Toyota Land Cruiser 5 Door - J120
Fits 2003 to 2009 Long Wheel Base models
This flange ball type tow bar is suitable for all normal and heavy duty towing and is therefore recommended for all car types, commercial and off road usage. This tow bar comes complete with all the fittings you will need to fit it to your vehicle, The only thing you will need to add to this tow bar kit, is the electrics.
| Symbol of the hook | T-166 |
| Ball type | E |
| Homologation e4 | download PDF |
| Disassemble the bumper | Yes |
| Cutting the bumper | Yes |
| Power and D [kN] | 16.3 |
| Cut off R [kg] | 2800 |
| Max vertical load S [kg] | 115 |
| Lifting weight [kg] | 18.1 |
| Assembly time [h] | 2.0 |
| Type of beam | WUD-05 |
Which Electric Kit Do I Need?
If you are only using the tow bar for a trailer or caravan then you will need a single electrics kit (12n)
If you are towing a caravan with the refrigerator running then you will need a double/twin electrics kit(12n & 12s).
